4 Beds, 3.0 Baths, 2045 SQ FT
81' Wide x 67' Deep
Plan No: 22_043
Couldn't load pickup availability
This stunning 4 bed ranch home features a compact layout with ample outdoor space and an eye-catching design.
- The primary bed suite is split from the secondary bedrooms and features an architectural bathroom and walk-in wardrobe.
- The living room includes a fireplace, adjacent family room and double doors out to the rear porch.
- The luxurious kitchen includes an eat-in island and a bay breakfast nook with 180 degree views out to the rear yard.
- The three secondary bedrooms fan out around the mud room which connects the 2 car garage and the laundry room and share two full sized bathrooms.
